Integrated box or retrofit box
Updated
If the windows are coming out, design the box with them. If the windows are staying, use a front-mounted box and accept that you will see it.
The difference that matters
Pretending a finished wall can grow a hidden lintel box without mess is how budgets double.
A roller, a screen, a venetian and a plantation panel are four answers.
The same pane, costed
The worked opening for Integrated box or retrofit box is 1.5 m wide by 1.5 m high, 2.25 square metres of glass. This figure puts 495 watts per square metre on the pane and uses a g-value of 0.76, about 846 watts into the room if the curtain is up. An opaque external shutter, taken as stopping 90 percent of that gain while it is fully down, leaves about 85 watts and keeps about 761 watts out. That is a noon figure for comparison. An internal blind does not get the same reduction. For Integrated box or retrofit box, use the noon figure to compare two openings on the same house, then let a measured survey replace the figure.
Fitted illustration for Integrated box or retrofit box in Sheffield: £2,150 at September 2026 prices, for this 1.5 by 1.5 m opening with a solar motor. The figure allows a front-mounted aluminium curtain and ordinary fixing. It does not include scaffold, a rebuilt soffit, planning drawings, or a new window. A second opening on the same visit usually costs less than the first, because the van is already there. Compare two quotes only when the slat, the box and the drive match.
The season people forget
Winter figure for Integrated box or retrofit box: glass at 2.6 W/m2K, 2.25 square metres, a 12 degree inside-outside gap and eight night hours. The bare pane is about 0.56 kWh a night on that crude sum. A closed shutter cutting about 30 percent of the flow leaves 0.39 kWh and saves about 0.17 kWh a night, only while it is down. Open it when you want winter sun.
Pick one job
Stop Integrated box or retrofit box if the solar panel would sit in a soffit with no sky, and the quote has no wired alternative. A photograph is not a manufacturing size.
If Integrated box or retrofit box is really a privacy job on a bay, price internal louvres and stop forcing a cassette to do joinery.
How to use the figure
The 1.5 by 1.5 metre opening inside Integrated box or retrofit box is there so a quote has something to disagree with. If the tape gives a different size, the tape wins.
The example drive is a solar motor, and the illustration is £2,150. A belt, a wired motor and a solar motor can share a curtain and still be different jobs. Compare those lines, not a single bold total.
What the survey still has to write down
For Integrated box or retrofit box, ask where the box lands, what colour reference will be ordered, and how the curtain opens when the motor is dead. Those three answers move the job more than a rounded price.
Leave the lantern, the side light and the next elevation off the order unless they are drawn. Integrated box or retrofit box covers one kind of opening. The house may have three.
When I would not order yet
Integrated box or retrofit box should wait if the opening is an escape door with no way to raise a dead motor, or if the front is the elevation a conservation area was drawn to protect.
A photograph is not a manufacturing size. Two quotes for Integrated box or retrofit box only compare when the slat, the box and the drive are the same kind of thing.
Questions worth asking the fitter
Is the price on this page a quote?
No. £2,150 illustrates Integrated box or retrofit box for a 1.5 by 1.5 metre opening with a solar motor, at September 2026 rates. Your survey replaces it.
Does the shutter cover every pane?
It covers the opening it is built for. Here that example is 2.25 square metres. A roof lantern, a side light or the next elevation is another line.
What if planning is unclear?
Do not pay the factory for Integrated box or retrofit box until a listed building, a conservation front, a flat or a shopfront has a written answer. Ordinary rear walls on houses are sometimes simpler.
What should two quotes share?
The same openings, the same slat type, and the same drive. Integrated box or retrofit box uses a solar motor in the example so you can see how much the motor choice moves £2,150.
